Furick Cup

Includes 1 cup mounted on collet body, 1 3/32-2.4mm slit style collet and 2 insulators CK & NONCK.

This is for 17 and 18 torches only. It can fit on 26 but you may have to run without an insulator. All torches are slightly different especially when it comes to the 17,18,26 size torches because all the manufacturers have their own idea on construction and we cannot guarantee the insulator will fit on every torch made in different countries but the Cup will screw on and can be used.

The Ally5 cups is an AC/DC polarity cup and has an amperage rating of 200 amps,

It is my “go to” cup when im welding thinner aluminum assemblies and need great visibility. It is made of Quartz laboratory grade glass and can withstand the high heat environments associated with welding on AC. Be careful not to slam cup and we do not recommend “walking the cup” with any Furickcups made of glass.

All glass cups are subject to pick up dirt and debris as are ceramic style cups. Use these accordingly and try to refrain from welding on dirty /oily applications that would spit back at glass and impede visibility.

Note only the Slit style collets will be compatible with the ally5 cups

BBWSG-19 Replacement Glass . Is only made to fit that model BBWSG-19 brass inset cup . The replacement glass includes 1 oring ( Oring included must be used with glass )
To install use provided oring and install on the brass BBWSG-19 Diffuser housing. Moisten the inside of the Glass cup and around the oring and gently push in . Be careful and do not force the Brass housing . If its difficult use more moisture .

Jazzy #10 kit  is the Fupa 12’s little sister , The Jazzy is made with the same patented diffuser as the fupa 12  just in a smaller package. She uses less gas for great results on mild steel typically 20 -25 CFH using   3/32 tungsten Size . You will get  2 glass cups, 1 spare diffuser and 4 orings . Please see the identify page if your new to the Furickcup products and you figure out what you will need to mount the cups to your torch. Please do not walk the Cup As we recommend with all the glass products . The ceramic versions are capable of walking.

Includes 2 full cups, spare diffuser and 1 titanium protector.

Carries an Issued US Patent on the Diffuser design has an inside diameter of .750 inches/ 19mm and is recommended for DC polarity applications only, It uses anywhere from 20-30 + CFH of Argon flow. It is recommended for 3/32 / 2.4mm tungsten size and carries a 180 amp rating on constant amperage. It can go higher if using pulse settings. It is hand made in the USA of Borosilicate laboratory grade glass. Due to the nature of the Glass “walking the Cup “ is not suggested.

Fupa 12 Mounting
If you have a #17, #18 or #26 size torch you will need a #17 kit.
If you have a #9 or #20 torch you will need to have a 45V44 gas lens, If you have one already you can surly use it , Keep in mind that import brands yield lower results.

Please see identify page for torch description

Fupa 12 is recommended for Mild steel, Stainless steel, Chromoly, Titanium, inconel and other space grade alloys. It works best on thinner / smaller applications such as header tubes and chassis tubing.

It is recommended you keep the diffuser the shape it comes and you remove and reinstall if it gets out of shape. Also it is recommended with all the BIG Diffuser cups that the user start off on low amps to stabilize the arc as to make sure you will not arc off diffuser. If diffuser arcing occurs you will have to clean/Regrind the tungsten. You will not hurt the diffuser on low amps but if arc with high amps you can deteriorate the Diffuser. Also be careful not to drop or hit cups against hard objects being we all know the nature of glass.

Comes with 2 cups, 3 o-rings and 1 spare diffuser.

Carries an Issued US Patent on the Diffuser design has an inside diameter of .750 inches/ 19mm and is recommended for DC polarity applications only, It uses anywhere from 20-30 + CFH of Argon flow. It is recommended for 3/32 / 2.4mm tungsten size and carries a 180 amp rating on constant amperage. It can go higher if using pulse settings. It is hand made in the USA of Borosilicate laboratory grade glass. Due to the nature of the Glass “walking the Cup “ is not suggested.

Fupa 12 Mounting
If you have a #17, #18 or #26 size torch you will need a #17 kit.
If you have a #9 or #20 torch you will need to have a 45V44 gas lens, If you have one already you can surly use it , Keep in mind that import brands yield lower results.

Please see identify page for torch description

Fupa 12 is recommended for Mild steel, Stainless steel, Chromoly, Titanium, inconel and other space grade alloys. It works best on thinner / smaller applications such as header tubes and chassis tubing.

It is recommended you keep the diffuser the shape it comes and you remove and reinstall if it gets out of shape. Also it is recommended with all the BIG Diffuser cups that the user start off on low amps to stabilize the arc as to make sure you will not arc off diffuser. If diffuser arcing occurs you will have to clean/Regrind the tungsten. You will not hurt the diffuser on low amps but if arc with high amps you can deteriorate the Diffuser. Also be careful not to drop or hit cups against hard objects being we all know the nature of glass.

Fupa #12 Ceramic and glass with cover includes

1 – Ceramic Fupa #12

1- Fupa #12  Glass with Titanium Cover ( Cover fits only on Glass version ) and Orings to mount

The Fupa series of cups fits on a 45V44 and a 17kit Please see the Identify page to determine your torch size . You may need to purchase an adapter kit for your 17 torch

We recommend if you have a #9 or #20 torch you get a brand name 45V44  some of the import brands yield poor results .

The Fupa series is recommended only for DC applications and is rated up to 200  non continuance amps. It is also for 3/32 -2.4mm tungsten size only.

NOTE:  the Diffusers in the cups are designed to work only with the Furickcup brand cups. We also recommend you buy a few spare diffusers to have, they are somewhat consumables and will eventually need to be replaced, The diffussers must be installed like you received them installed and must seal tightly around the cup or you will have poor results. They are designed to  have a gap between the 2 layers of screens and it is recommended you install them back that way, It may take a few tries to get the screens in properly but have patience , The cupped side goes in first .

The ally 5 cup comes with 1 cup mounted on collet body and insulator needed to mount on 9 or 20 torch.
The Ally5 cups is an AC/DC polarity cup and has an amperage rating of 200 amps,
It is my “go to” cup when im welding thinner aluminum assemblies and need great visibility. It is made of Quartz laboratory grade glass and can withstand the high heat environments associated with welding on AC. Be careful not to slam cup and we do not recommend “walking the cup” with any Furickcups made of glass.
All glass cups are subject to pick up dirt and debris as are ceramic style cups. Use these accordingly and try to refrain from welding on dirty /oily applications that would spit back at glass and impede visibility.

3/32in- 2.4mm 45V44 Genuine CK Brand Gas Lens

SOLD SINGLE

Full BBWSG-19 Cippy  Edition .   With Furick Cup  Brass gas lens installed ,

The Cippy is a Thermoplastic Version of the Popular Glass  BBWSG-19.  The plastic will  handle 150 – 170 DC amps  using 3/32 tungsten  under light to normal conditions .

This is NOT WALKABLE and Avoid touching the Plastic to Hot surfaces of welding.

The Thermoplastic is recommended for Light Gauge Work. For Longevity  Keep out of extreme heat for long periods of time .

Comes installed with 3/32  diffuser

If you have a 17 torch you will need a 17,18 and 26 torch mount kit available in the 17 torch section of the Shop page ,

For 9/20 torches you need a 45V44 3/32 gas lens available in the 9/20 torch section of the shop page
