Furick Cup

1/16in-1.6mm Wedge collet for stubby gas lens 11617GL

These will need proper gas lenses and these will fit on the 17 adapter kit

This will fit all listed size torches and is compatible with the #17, #18 and #26 kit as well as the Ally 5.

Genuine Furick

Made in USA

O’ring Groove machined in thread for Glass cups

Stubby Gas lens for 1/8in-3.2mm Tungsten

17,18 and 26 torches

You will need  proper collet   COL12517W

3/32-2.4mm  Genuine Furick

Made in USA

O’ring Groove machined in thread for Glass cups

will fit on 17 adapter kit also you will need proper collets to install COL11617W

44V43 will be you 1/16in-1.6mm gas lens for the 9/20 series torches GENUINE CK BRAND !!!!!

SOLD SINGLE

Comes with 1 full cup, 1 spare diffuser and o-rings for mounting.

Carries an Issued US Patent on the Diffuser design has an inside diameter of .875 inches / 22mm and is recommended for DC polarity applications only, It uses anywhere from 25-30 + CFH of Argon flow. It is recommended for 3/32 / 2.4mm tungsten size and carries a 180 amp rating on constant amperage. It can go higher if using pulse settings. Hand made in the USA of Borosilicate laboratory grade glass. Due to the nature of the Glass “walking the Cup“ is not recommended.

Moose Knuckle 14 Mounting

If you have a #17, #18 or #26 size torch you will need a #17 kit ,

If you have a #9 or #20 torch you will need to have a 45V44 gas lens, If you have one already         you can surly use it, Keep in mind that import brands yield lower results .

Moose Knuckle 14 is recommended for Mild steel, Stainless steel, Chromoly, Titanium, Inconel and other space grade alloys. It works best on thinner /smaller to medium applications such as header tubes, chassis tubing and flat welding applications.

It is recommended you keep the diffuser the shape it comes and you remove and reinstall if it gets out of shape. Also it is recommended with all the BIG Diffuser cups that the user start off on low amps to stabilize the arc as to make sure you will not arc off diffuser. If diffuser arcing occurs you will have to clean/regrind the tungsten. You will not hurt the diffuser on low amps but if arc with high amps you can deteriorate the Diffuser. Also be careful not to drop or hit cups against hard objects being we all know the nature of glass.

1/8in-3.2mm Wedge collet for the 17,18 and 26 torches .

These must use the 12517GL Gas lens

These are hard to beat with the extreme heat of the bigger diameter torches !!!

10 pieces of High temperature silicon o’rings . These are the o’rings needed to mount the glass cups to your torch

Same great #14 as the glass version , This full ceramic model comes with and spare screen and this model threads on your 45V44 gas lens if you have a 9 or 20 torch , Or if you have a 17,18 or 26 torch you will need the adapter kit , This cup is recommended for DC only and 3/32 tungsten. It will give best results with 25-30 CFH of argon flow.
A few tips
Keep tungsten clean at all times
Start arc at a low amperage , Establish Arc on tip of tungsten then roll into the desired amperage, If arc wanders clean tungsten or damage to the Screen Diffuser is possible.
Keep screen in the shape it comes with and try not to deform the screen, If screen replacement is needed make sure Screen is sealed against the walls of the cup or undesired results may occur.
