Powdercoated Aluminum Mounting Bracket for the ECUMaster EMU, Black Apprendre encore plus

The CAN H-Bridge device contains two independent H-Bridges with over-current and short circuit protection, capable of 10A continuous current and 30A peak current. H-Bridges can be controlled via device inputs or CAN bus messages. Voltage range: 6V - 28V (12V and 24V automotive installations) Output current: 10A continuous, 30A peak 4 analogue (0-5V) / digital (35Hz - 200Hz PWM) inputs Output PWM: 12bit 3.9kHz The CAN H-Bridge device can be used to supply protected low side (GND) or high side (VBat) supply independently to each of 4 outputs for bidirectional DC motor control. Low side outputs can be PWM modulated on per-bridge basis. Apprendre encore plus

8 channel CAN EGT Module Apprendre encore plus

Small PCB module to transmit 8 switched inputs and 8 analog inputs (from rotary potentiometers) over CAN network, i.e. for steering wheel buttons, rotary switches and indicators. Apprendre encore plus

Communicates with EMU w/ CAN Bus to add an additional 4 Analog Inputs Apprendre encore plus

Enables use of DBW Throttle Body with the EMU Apprendre encore plus

Serial Bluetooth adapter for Android devices and tablets, allows use of phone or tablet to display customizable gauges in real time Apprendre encore plus

Serial Datalogger with bluetooth capability, records all EMU/EMU Black log channels to SD card Apprendre encore plus

8 position switch for boost control/traction control settings Apprendre encore plus

Lambda to CAN controller is a compact device used to control a Bosch LSU 4.9 wideband oxygen sensor and transmit the lambda reading via CAN-BUS. Two programmable 0-5V analog signal lines are available, along with CAN transmission. Apprendre encore plus
